Raspberry Pi Compute Module 4

Compute Module 4 (CM4) brings the power of Raspberry Pi 4 to the popular Compute Module family. Spec Form factor: 55 mm × 40 mm Processor: Broadcom BCM2711 quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz Memory: 1GB, 2GB, 4GB or 8GB LPDDR4 (depending on variant) Connectivity: Optional wireless LAN, 2.4GHz and 5.0GHz IEEE 802.11b/g/n/ac wireless, Bluetooth 5.0, BLE with onboard and external antenna options Onboard Gigabit Ethernet PHY supporting IEEE1588 1 × USB 2.0 interface PCIe Gen 2 x1 interface 28 GPIO signals SD card interface for SD card or external eMMC (for use only with Compute Module 4 variants without eMMC) Video: Dual HDMI interface (up to 4Kp60 supported) 2-lane MIPI DSI display interface 2-lane MIPI CSI camera interface 4-lane MIPI DSI display interface 4-lane MIPI CSI camera interface Multimedia: H.265 (4Kp60 decode); H.264 (1080p60 decode, 1080p30 encode); OpenGL ES 3.0 graphics Input power: 5V DC Operating temperature: 0 to 80°C Documents Raspberry Pi 4 Compute Module 4 product brief Raspberry Pi Compute Module 4 datasheet Compute Module 4 STEP file Compute Module 4 Lite (without eMMC) STEP file All CM4 models SKU Wireless Ram Storage CM4101000 Yes 1 GB Ram 0 GB eMMC CM4101008 Yes 1 GB Ram 8 GB eMMC CM4101016 Yes 1 GB Ram 16 GB eMMC CM4101032 Yes 1 GB Ram 32 GB eMMC CM4102000 Yes 2 GB Ram 0 GB eMMC CM4102008 Yes 2 GB Ram 8 GB eMMC CM4102016 Yes 2 GB Ram 16 GB eMMC CM4102032 Yes 2 GB Ram 32 GB eMMC CM4104000 Yes 4 GB Ram 0 GB eMMC CM4104008 Yes 4 GB Ram 8 GB eMMC CM4104016 Yes 4 GB Ram 16 GB eMMC CM4104032 Yes 4 GB Ram 32 GB eMMC CM4108000 Yes 8 GB Ram 0 GB eMMC CM4108008 Yes 8 GB Ram 8 GB eMMC CM4108016 Yes 8 GB Ram 16 GB eMMC CM4108032 Yes 8 GB Ram 32 GB eMMC CM4001000 No 1 GB Ram 0 GB eMMC CM4001008 No 1 GB Ram 8 GB eMMC CM4001016 No 1 GB Ram 16 GB eMMC CM4001032 No 1 GB Ram 32 GB eMMC CM4002000 No 2 GB Ram 0 GB eMMC CM4002008 No 2 GB Ram 8 GB eMMC CM4002016 No 2 GB Ram 16 GB eMMC CM4002032 No 2 GB Ram 32 GB eMMC CM4004000 No 4 GB Ram 0 GB eMMC CM4004008 No 4 GB Ram 8 GB eMMC CM4004016 No 4 GB Ram 16 GB eMMC CM4004032 No 4 GB Ram 32 GB eMMC CM4008000 No 8 GB Ram 0 GB eMMC CM4008008 No 8 GB Ram 8 GB eMMC CM4008016 No 8 GB Ram 16 GB eMMC CM4008032 No 8 GB Ram 32 GB eMMC
